§ automatischer Abschalter der LNB-Spannung
§ Kurzschluss-Sicherung (12/18V;0/22KHz)
§ 5in/8out mit energiesparendesNetzteil
§ DiSEqC 2.0
§ 4 Jahre Garantie
§ quadtauglich
§ Frequency range LNB inputs 950-2300 MHz
§ Terr. input 5-862 MHz (passive)
§ 40-862 MHz (active)
§ Outputs 5-2300 MHz (passive)
§ 40-2300 MHz (active)
§ Control 13/18 V + 0/22 kHz
§ Insertion loss Sat. 4 dB avg
§ Terr. active 3 dB avg
§ Terr. passive 20 dB avg
§ Sat. inputs isolation 20 dB min
§ Maximum input level* Sat. 90 dBµV avg
§ Terr. 100 dBµV avg (passive)
§ 93 dBµV avg (active)
§ Maximum output level* Sat. 86 dBµV avg
§ Terr. 80 dBµV avg (passive)
§ 90 dBµV avg (active)
§ Power consumption From each receiver 40 mA (18 V)
§ From internal power supply 4 W (passive)
§ 6 W (active) + LNB
§ Terr. preamplifier supply 100 mA max (12 V DC)
§ Dimensions (w,d,h) 27.0 x 15.2 x 8.7 cm
§ (power cord length 130 cm)
§ Temperature range -30 ~ +70 °C
§ *Terr.: EN 50083-3/60dB IMA3 [dBµV]; SAT: EN 50083-3/35dB IMA3 [dBµV]
